4 side seal bag machine is a high-tech machine,

It combines the advanced technology reserve of the contemporary era.

Longitudinal sealing device
Structures: Composite Bridge Structures
Drive: Main Motor Drive Power Rod
Drive: Vertical motion of eccentric connecting rod

Function Indication

1.      Application scope

Material:  various compound film

Roll folding

Max Width

             1000mm

Max Diameter

                          700mm



2.      Adaptability

Bagging speed

160 shots/min  (mechanical design speed)

Bagging width

Max Width

500mm

Bagging length

40-400mm

Notes: When the length above 400mm, change into skip mode.

      Actual speed is according to different type of bags or materials.



3.      Driving Mode

Feeding traction : drove by AC servomotor.

Upper and lower press: drove by AC servomotor or AC motor.

Notes: customer can choose by self demand.





4.      Control Mode

Control system based on industrial PC.

Adopts PLC to control , touching screen displaying.

System adopts multiple photoelectric control.



5.      Functions

Temperature : 0-300℃ non-contact automatic control , Touch screen displaying .

Counter : preset is available .

Conveyer : conveyer time can be preset .

Punching device : punching time can be preset , and punch mode can be set as continuous or interval .

Working mode:Color label mode or fixed length mode.

Skip mode : twice to ninety-nine times .

Selectivity : feeding without movement , upper & lower regulating trimmer can be selected.

Message alert : lost of photoelectricity , warping alarm ,servomotor alarm ,tension alarm and auto-switch off the machine .


6.       Electricity-use configuration

Feeding driving AC motor

1.5 kw  ×  2  =  3.0 kw

Heater Up & Down AC motor

3.7 kw  ×  1  =  3.7 kw

Unwinding motor

0.55kw ×  1  =  0.55 kw

Longitude sealer

6 kw  ×  2  =  12.0 kw

Cross sealer

6 kw  ×  3  =  18 kw

Molding sealer

2 kw  ×  2  =  4 kw

Control system and others

1.0 kw

Total power consumption

Approx.  43 kw

Gas pressure

0.6MPa (6kwfim²)

Cooling water

Approx. 15L/min

Occupying area of equipment

Approx.   10.5 m ×1.9m

Gross weight of equipment

Approx.   5.5t



4 Side Seal Bag Machine
